48V 100Ah [Peak 200A] Lithium RV & Golf Cart Battery (RG51105) 51.2V 105Ah 100Ah

  • MOQ: 5
  • Delivery: 25 Days
  • OEM / ODM
  • FOB, EXW, CIF
  • FedEx, DHL, UPS, TNT
  • Air, Sea, Land Transport
  • 10FT, 20FT, 40FT, 60FT Container

Description

The 48V 100Ah Lithium Battery (RG51105) is a top-tier power solution designed to cater to the needs of OEMs, ODMs, and wholesale buyers in the electric vehicle industry. This versatile battery is suitable for golf carts, RVs, electric scooters, and other low-speed vehicles, providing reliable and efficient power for a variety of demanding applications.

Key Features:

  • High Energy Capacity: Operating at a nominal voltage of 51.2V with a capacity of 105Ah, this battery offers 5.376 kWh of energy. It delivers a typical range of 60-80 km (37-50 miles) per charge, ensuring long-lasting performance for both golf carts and RVs.
  • Compact and Lightweight: Weighing just 43 kg (94.8 lb) and measuring 500 x 355 x 247 mm (19.7 x 14 x 9.7 inches), this 48V 100Ah lithium battery is designed for easy installation in various applications, from electric scooters to RVs and golf carts.
  • Extended Cycle Life: With the ability to endure over 6000 charge cycles at 80% depth of discharge (DOD), this battery ensures long-term reliability and offers excellent cost-effectiveness for businesses and end users.
  • Peak Discharge Performance: The battery supports a peak discharge current of 250A for up to 30 seconds, making it ideal for high-demand applications, such as electric floor scrubbers and heavy-duty RV systems.
  • Customizable Features: Optional upgrades such as Bluetooth connectivity, GPS tracking, and self-heating features are available, enhancing user experience and adaptability across various applications.

Product Overview:

The 48V 100Ah Lithium Battery (RG51105) is designed using advanced LiFePO4 technology, ensuring efficient and secure energy storage. The built-in DALY BMS (Battery Management System) offers enhanced protection against overcharging, deep discharges, and thermal issues, ensuring safe and reliable operation.

This battery meets international standards, with certifications including UL1642, IEC62133, CE, MSDS, and UN38.3. It is the ideal choice for businesses seeking to improve their electric vehicle offerings, whether for golf carts, RVs, or electric scooters.

Choose the 48V 100Ah Lithium Battery to provide your customers with a dependable and efficient energy source for their electric vehicles, ensuring reliable performance and durability for various applications.

Specifications

  • ApplicationsGolf Carts, LSV, LEV, Sightseeing Car, Electric Scooter, Electric Rickshaw, Electric Trishaw, AGV, AMR, etc
  • Cell TypeLiFePO4 (LFP)
  • Rated Voltage51.2V
  • Rated Capacity105Ah
  • Rated Energy5.376 kWh
  • Dimensions (L*W*H)500 × 355 × 247 mm / 19.7 × 14 × 9.7 inches
  • Weight43 kg / 94.8 lb
  • Max Charge Voltage58.4V
  • Discharge Cut-off Voltage40V
  • Standard Charge Current22A (5h)
  • Max Continuous Charge Current100A
  • Max Continuous Discharge Current100A
  • Peak Discharge Current200A (10S)
  • Typical Mileage Per Full Charge60–80 km / 37–50 miles
  • Self-discharge2% per month
  • Cycle Life6000 Cycles (@80% DOD)
  • Max Parallel Connection4
  • IP Rating66
  • TerminalM8
  • BMSDALY BMS
  • CommunicationRS485
  • LCD DisplayOptional
  • Power SwitchYes
  • Optional UpgradesBluetooth, App, Self-heating, CAN-bus, WiFi, 4G, GPS, RS232, LCD Display, Circuit Breaker, Heatsink, Fans Cooling, Anti-theft, Solar MPPT, Active Balance, etc.
  • Charge Temperature0°C ~ 60°C / 32°F ~ 140°F
  • Discharge Temperature-20°C ~ 60°C / -4°F ~ 140°F
  • Storage Temperature0°C ~ 45°C / 32°F ~ 113°F
  • Design Life10 Years
  • User ManualYes
  • Silkscreen / Label / Laser LogoYes
  • OEMYes
  • CertificationUL1642, IEC62133, CE, MSDS, UN38.3
  • ExportAfrica, Europe, Middle East

FAQs

What is a 48V 100Ah lithium golf cart battery?

A 48V 100Ah lithium golf cart battery is a high-capacity energy solution designed for electric vehicles. Operating at a nominal voltage of 51.2V and providing a capacity of 105Ah, it delivers 5.376 kWh of energy, ensuring reliable power for applications such as golf carts, electric scooters, and low-speed vehicles.

How long does a fully charged 48V 100Ah battery last?

A fully charged 48V 100Ah battery typically allows for a range of 60-80 km (37-50 miles) per charge under normal conditions. This makes it suitable for extended use in electric vehicles, allowing users to travel significant distances without frequent recharging.

What are the key features of this battery?

Key features of the 48V 100Ah lithium battery include high energy density (5.376 kWh), long cycle life (over 6000 cycles at 80% depth of discharge), built-in safety protections, and optional upgrades like Bluetooth connectivity and GPS tracking to enhance functionality and user experience.

What are the specifications of the battery?

Specifications include a nominal voltage of 51.2V, capacity of 105Ah, dimensions of 500 x 355 x 247 mm (19.7 x 14 x 9.7 inches), weight of 43 kg (94.8 lb), maximum charge voltage of 58.4V, and an operating temperature range from -20°C to 60°C for discharge.

Is the battery compatible with all electric vehicles?

Compatibility depends on the specific voltage requirements and dimensions of the electric vehicle. Ensure that your vehicle operates on a 48V system and that the battery fits within its designated compartment to guarantee optimal performance.

How can I maximize the lifespan of my battery?

To maximize lifespan, avoid deep discharges, use a charger specifically designed for lithium batteries, and store the battery within recommended temperature ranges. Regularly inspect connections and terminals to ensure they are secure and free from corrosion for optimal performance.
